Description
Features
- Operating water temperature up to 55°C
- Max working pressure 5.5 kg/cm2
- High suction with self-priming pump up to 8 meter
- Low power consumption
- Wide voltage operating range (180-240V)
- The direction of rotation: Anti-Clockwise when viewed from the driving end
Application
- Used in gardening, Farmhouse & building construction
- For lifting water overhead storage tanks
- Pressure booster systems
- Hotels, hospitals, and fountains
- Water circulation in industries
Motor
- Motor body: High-quality aluminum pressure die-casted and extruded
- Motor Stator: Low watt loss silicon steel laminations (CRNO)
- TEFC motor (2Pole/4Pole) suitable for 180-240V, 50 Hz single-phase AC power supply
- In-built thermal overload protector (T.O.P.)
- Motor insulation Class F / Class B
- Motor protection IP-55 / IP-66
Pump Construction
- Pump casting: Grey Cast iron
- Impeller: Forged brass* for longer life
- Shaft: Stainless steel / EN8
- Mechanical seal*: Silicon carbide-graphite • Copper winding.
